31NB-11150 31NB-11151 Swing Reduction Gear Box ,Device for R450LC-7 R500LC-7
aftermarket replacement parts,
NEW ,IN STOCK
USA BASED SELLER
IMPORTANT NOTE
Please verify the product details through the video to confirm that the product can fit your machine. For any reason to return, you need to
be responsible for the round-trip shipping, please note.
Orders are delivered through LTL for that reason the shipping address must be able to accommodate a full size truck/semi-truck with trailer.
You must indicate if your shipping will be delivered for commercial or residential address (Limited Access).
THIS LISTING WILL BE NORMAL SHIPPING ONLY FOR COMMERCIAL/BUSINESS ADDRESS IN THE CASE OF:
Residential OR Limited access areas shippings will have an additional charge of $120
If you need lift gate, it will have an additional charge of $120
OTHER AVAILABLE SWING REDUCTION AND TRAVEL REDUCTION PART
PINION SHAFT ,GEAR SUN,GEAR RING ,SPIDER ,PIN,BEARING SPHERICAL ,OIL SEAL ,FLATING SEAL ,HOUSING ,BEARING NEEDLE ,CARRIER ,GEAR PLANETARY,SHIM, COVER ,COUPLING ETC
OTHER AVAILABLE SWING MOTOR PARTS AND TRAVEL MOTOR PARTS:
CYLINDER BLOCK,PISTON ,SET PLATE ,SHOE PLATE,SHAFT ,BALL GUIDE,SPRING,PLATE FRIC,PLATE STEEL,SEAL KIT,RELIAF VALVE ,OIL SEAL ,VALVE PLATE,
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| *. | @ | [1] | SWING MOTOR ASSY | SEE 4101 |
| *-2. | 31NB-11150 | [1] | SWING REDUCTION GEAR | |
| *-2. | 31NB-11151 | [1] | SWING REDUCTION GEAR | |
| 1. | XKAQ-00297 | [1] | CASING | |
| 1. | XKAQ-00963 | [1] | CASING | |
| 2. | XKAQ-00282 | [1] | SHAFT-DRIVE | |
| 3. | XKAQ-00018 | [1] | SPACER | |
| 5. | XKAQ-00026 | [1] | BEARING-ROLLER | |
| 6. | XKAQ-00032 | [1] | SEAL-OIL | |
| 7. | XKAQ-00029 | [1] | BEARING-ROLLER | |
| 8. | XKAQ-00283 | [1] | PLATE-THRUST 3 | |
| 9. | XKAQ-00075 | [1] | CARRIER 2 | |
| 10. | XKAQ-00074 | [1] | RING-STOP | |
| 11. | XKAQ-00284 | [1] | GEAR-RING | |
| 12. | XKAQ-00286 | [2] | PIN-KNOCK | |
| 13. | XKAQ-00287 | [1] | GEAR-PINION | OLD |
| 13. | XKAQ-00978 | [1] | GEAR-PINION | NEW |
| 14. | XKAQ-00288 | [6] | WASHER-THRUST | |
| 15. | XKAQ-00023 | [3] | GEAR-PLANET 2 | |
| 16. | XKAQ-00070 | [3] | PIN 2 | INCL 23 |
| N23. | @ | [3] | BUSHING 2 | |
| 17. | XKAQ-00048 | [6] | PIN-SPRING | |
| 18. | XKAQ-00289 | [1] | GEAR-SUN 2 | |
| 19. | XKAQ-00290 | [1] | CARRIER 1 | |
| 20. | XKAQ-00057 | [3] | PLATE-SIDE 1 | |
| 21. | XKAQ-00019 | [3] | PIN 1 | |
| 22. | XKAQ-00030 | [3] | CAGE-NEEDLE | |
| N23. | @ | [3] | BUSHING 2 | |
| 24. | XKAQ-00025 | [3] | GEAR-PLANET 1 | |
| 25. | XKAQ-00292 | [1] | WASHER-LOCK | |
| 26. | XKAQ-00293 | [1] | PLATE-SIDE 3 | |
| 27. | XKAQ-00294 | [1] | GEAR-SUN 1 | |
| 28. | XKAQ-00047 | [1] | RING-STOP | |
| 29. | XKAQ-00273 |
