K1003134 TRAVEL REDUCTION Device ,Gear Box Fits for DX340LC DX350LC DX360LC
| # | Part No | Part Name | Comment | Qty. | Price request |
|---|---|---|---|---|---|
| - | K1003134 | TRAVEL REDUCTION GEAR | 2 | ||
| 1 | 104-00035 | GEAR, RING | 33 kg | 1 | |
| 2 | 1.402-00129 | HOUSING | 49 kg | 1 | |
| 4 | 1.430-00216 | COVER, SIDE | 12 kg | 1 | |
| 5 | 1.230-00009 | CARRIER NO.1 | 54 kg | 1 | |
| 6 | 1.230-00015 | CARRIER NO.2 | 10 kg | 1 | |
| 9 | 404-00080 | GEAR, SUN NO.1 | 1 kg | 1 | |
| 10 | 404-00081 | GEAR, SUN NO.2 | 2 kg | 1 | |
| 11 | 404-00082 | GEAR, SUN NO.3 | 6 kg | 1 | |
| 12 | 1.403-00061 | GEAR, PLANETARY NO.1 | 1 kg | 3 | |
| 13 | 1.403-00065 | GEAR, PLANETARY NO.2 | 1 kg | 3 | |
| 14 | 104-00036 | GEAR, PLANETARY NO.3 | 3 kg | 4 | |
| 16 | K9002264 | PIN NO.2 | 1 kg | 3 | |
| 17 | 123-00285 | PIN NO.3 | 1 kg | 4 | |
| 18 | 1.412-00121 | PLATE, SIDE E | 3 | ||
| 19 | 1.412-00117 | PLATE, SIDE A | 6 | ||
| 20 | 412-00038 | PLATE, SIDE F | 8 | ||
| 21 | 1.216-00017 | CAGE, NEEDLE | 3 | ||
| 22 | 1.216-00015 | CAGE, NEEDLE | 3 | ||
| 23 | 1.216-00018 | CAGE, NEEDLE | 4 | ||
| 24 | 1.115-00232 | RING, INNER | 3 | ||
| 25 | 110-00126 | BUSH, FLOATING | 1 kg | 4 | |
| 26 | 114-00347 | RING, THRUST 60 | 2 | ||
| 27 | 114-00348 | RING, THRUST 90 |
