YN15V00003S009 SHAFT FITS KOBELCO SK200-5 SK200LC-5 SK200 MARK V TRAVEL MOTOR ,
AFTERMARKET PARTS,
NEW ,
FAST SHIPPING BY FEDEX OR UPS 1-5 DAYS ARRIVE ,
USA BASED SELLER
OHTER AVAILABLE PARTS:
YN15V00003F1 [1] HYDRAULIC MOTOR KOB ASSY (PROPELLING) Superseded by part number: YN15V00003F2
. . YN15V00003F2 [1] HYDRAULIC MOTOR KOB ASSY (PROPELLING)
1. YN15V00003S001 [1] CASE (FOR F1,F2 ONLY) CASE (FOR F1,F2 ONLY)
2. YN15V00003S002 [1] COVER KOB (FOR F1,F2 ONLY)
3. YN15V00003S003 [1] CYLINDER KOB CYLINDER(FOR F1,F2 ONLY)
4. NSS [1] NOT SOLD SEPARAT CON RETAINER(FOR F1,F2 ONLY)
5. 2441U783S5 [3] CLUTCH PLATE KOB (FOR F1,F2 ONLY) Superseded by part number: YN15V01005F2
6. YN15V00003S006 [1] PISTON KOB BRAKE(FOR F1,F2 ONLY)
7. 2441U783S7 [4] STEP PLATE KOB SEPARATE(FOR F1,F2 ONLY)
8. YN15V00003S008 [1] PILOT VALVE KOB VALVE(FOR F1,F2 ONLY)
9. YN15V00003S009 [1] SHAFT KOB SHAFT(FOR F1,F2 ONLY)
10. YN15V00003S010 [1] COUPLING KOB FOR F1,F2 ONLY)
11. NSS [1] NOT SOLD SEPARAT CON PLATE, SHOE(FOR F1,F2 ONLY)
12. NSS [1] NOT SOLD SEPARAT CON JOINT, BALL(FOR F1,F2 ONLY)
13. YN15V00003S013 [1] SPRING KOB SPRING(FOR F1,F2 ONLY)
14. NSS [9] NOT SOLD SEPARAT CON PISTON ASSY(FOR F1,F2 ONLY)
15. YN15V00003S015 [1] O-RING KOB O-RING(FOR F1,F2 ONLY) Superseded by part number: YN15V00017S063
16. YN15V00003S016 [1] O-RING KOB (FOR F1,F2 ONLY) Superseded by part number: LS15V00004S052
17. 2441U783S20 [3] CHECK VALVE KOB CHECK(FOR F1,F2 ONLY)
18. ZR26X06200 [1] SNAP RING KOB RETAINING(FOR F1,F2 ONLY)
19. ZR26X08000 [1] SNAP RING KOB Retaining -- ID 80 x OD 85.5 x Th 2.5mm, (FOR F1,F2 Only)
20. ZR16X04000 [1] RING KOB Retaining -- ID 37 x OD 40 x Th 1.8mm, (FOR F1,F2 Only)
21. NSS [1] NOT SOLD SEPARAT CON PISTON(FOR F1,F2 ONLY)
22. NSS [1] NOT SOLD SEPARAT CON BALL, HALF(FOR F1,F2 ONLY)
23. NSS [2] NOT SOLD SEPARAT CON PIVOT(FOR F1,F2 ONLY)
24. YN15V00003S024 [1] SEAL KOB PISTON(FOR F1,F2 ONLY)
25. 2436U1123S14 [1] ORIFICE KOB ORIFICE(FOR F1,F2 ONLY)
26. 2436U812S4 [1] PLUG (FOR F1,F2 ONLY) PLUG (FOR F1,F2 ONLY)
27. YN15V00003S027 [1] GASKET KOB OIL SEAL(FOR F1,F2 ONLY)
28. 2441U783S30 [3] SPRING KOB (FOR F1,F2 ONLY)
29. YN15V00003S029 [9] SPRING KOB (FOR F1,F2 ONLY)
30. YN15V00003S030 [11] SPRING KOB (FOR F1,F2 ONLY)
31. YN15V00003S031 [1] BEARING KOB
32. YN15V00003S032 [1] NEEDLE BEARING KOB BEARING, NEEDLE(FOR F1,F2 ONLY)
33. ZS23C16045 [8] CAP,Hex Socket Head, M16 x 45mm KOB Screw -- M16x2.0x45mm, (FOR F1,F2 Only)
34. ZP26D10022 [1] PIN KOB (FOR F1,F2 ONLY)
35. YN15V00003S035 [1] O-RING KOB (FOR F1,F2 ONLY)
36. ZD12P00600 [3] O-RING KOB ID 05.80 ± 0.15 x OD 09mm, (FOR F1,F2 Only)
37. ZD12P00800 [2] O-RING,1.9mm Thk x 7.8mm ID, 90 Duro KOB ID 7.8mm x OD 9.7mm, (FOR F1,F2 Only)
38. ZD12P00900 [3] O-RING KOB ID 08.80 ± 0.17 x OD 12mm, (FOR F1, F2 Only)
39. YN15V00003S039 [1] O-RING KOB O-RING(FOR F1,F2 ONLY)
40. 2436R866F1 [2] PILOT VALVE KOB ASSY.OVERLOAD RELIEF (FOR F1,F2 ONLY)
41. 2436R874F1 [1] VALVE KOB ASSY, PILOT(FOR F1,F2 ONLY)
42. YN23V00001F1 [1] BRAKE VALVE KOB ASSY(FOR F1,F2 ONLY)
43. NSS [1] NOT SOLD SEPARAT CON NAME PLATE
44. ZR26X03200 [1] SNAP RING KOB Retaining -- ID 32 x OD 34.4 x Th 1.2mm
. . YN15V01005F2 [1] REPAIR KIT KOB PLATE Repair Kit (includes 2441U783S5 x 3 & 2441U783S7 x 4)
. . YN15V00003R100 [1] PISTON KOB REPAIR KIT CONSISTS OF ITEM 14(FOR F1,F2 ONLY)
. . YN15V00003R200 [1] REPAIR KIT KOB CONSISTS OF ITEM 4,12(FOR F1,F2 ONLY)
. . YN15V00003R300 [1] REPAIR KIT
